Display Gyro 35
Model: DL3367
Downlight for indoor use. Compact size; Delicate design; Short and long snoot version availble; Precise light direction control; Suitable for use as under-cabinet/shelf, reading, and other focused luminaries;
Color: 102 Textured Black
Spec overview
System Power
2.1W
Lumens(at 3000K)
120lm
LED CCT
2700K/3000K/4000K
Beam
20°/30°/40°
Specifications
Light source
Luminus SST20 Chip
Output (W)
700mA 3V 3W
Total power consumption (W)
3
Color temperature:
2700K/3000K/4000K
CRI
≧90
Photobiological risk
RG1
Real Lumen
140
Qty Leds
1
Lm/Real W
70
Life Time
50.000h L90B20
MacAdam steps
3
UGR
24(Short snoot); 13(Long snoot)
Warranty
Damage caused by misuse
Your product has a warranty that protectsagainst defects in the material and thefinishing of the product in accordance with it'smaintenance and usage instructions.
5 year warranty
Your product has a warranty that protectsagainst defects in the material and thefinishing of the product in accordance with it'smaintenance and usage instructions.
Resources
Display Gyro 35
Catalogue
Display Gyro 35
Datasheet
Display Gyro 35
Instructions
