Commercial Office 190
Model: DL3540
Deep recessed & slim trim; Interchangeable buffle in various finishing; IP54 ingress protection; Ultra low-glare;
Color: 102 Textured Black
Spec overview
System Power
20.7W
Lumens(at 3000K)
1723lm
LED CCT
2700K/3000K/4000K
Beam
24°/38°/60°
Specifications
Light source
Citizen 1204
Output (W)
18W (500mA, 36V)
Total power consumption (W)
20W
Color temperature
2700K/3000K/4000K
CRI
≥90
Photobiological risk
RG1
Real Lumen
1723lm
Qty Leds
1
Lm/Real W
81.71lm
Life Time
50.000h L90B10
MacAdam steps
3
UGR
<19
Warranty
Damage caused by misuse
Your product has a warranty that protectsagainst defects in the material and thefinishing of the product in accordance with it'smaintenance and usage instructions.
5 year warranty
Your product has a warranty that protectsagainst defects in the material and thefinishing of the product in accordance with it'smaintenance and usage instructions.
Resources
Commercial Office 190
Catalogue
Commercial Office 190
Datasheet
Commercial Office 190
Instructions
Commercial Office 190
IES
