Display Micro Fix 17
Model: DL3766
Adaptor ring available in dual color; IP44;
Color: 102 Textured Black
Spec overview
System Power
1.7W
Lumens(at 3000K)
80lm
LED CCT
2700K/3000K/4000K
Beam
15°/20°/36°
Specifications
Light source
Osram SSL150
Output (W)
350mA 3V
Total power consumption (W)
1W
Color temperature
2700K/3000K/4000K
CRI
90
Photobiological risk
RG1
Real Lumen
80lm
Qty Leds
1
Lm/Real W
44.78lm
Life Time
50.000h L90B20
MacAdam steps
3
UGR
14
Warranty
Damage caused by misuse
Your product has a warranty that protectsagainst defects in the material and thefinishing of the product in accordance with it'smaintenance and usage instructions.
5 year warranty
Your product has a warranty that protectsagainst defects in the material and thefinishing of the product in accordance with it'smaintenance and usage instructions.
Resources
Display Micro Fix 17
Catalogue
Display Micro Fix 17
Datasheet
Display Micro Fix 17
Instructions
Display Micro Fix 17
IES
